General description
The Evolution R185SMS+ is a compact and powerful 185mm sliding compound mitre saw designed for versatility and precision. It features advanced Multi-Material cutting technology, allowing it to effortlessly cut through a variety of materials including plastics, soft and hardwoods, sheet metal, aluminum, mild steel profiles, and copper pipe. This saw is ideal for both home workshops and on-site installations, making it a valuable addition to any toolkit.Technical specifications
- Motor Power: 1200W
- Speed No Load: 3700 min-1
- Max. Mitre Angle: 50 degrees - 50 degrees
- Max. Bevel Angle (Left): 45 degrees
- Blade Diameter: 185mm
- No. of Teeth: 20
- Bore: 20mm
- Kerf: 1.7mm
- Max. Cross Cut (0 degrees x 0 degrees): 210mm x 55mm
- Max. Bevel Cut (0 degrees x 45 degrees): 210mm x 38mm
- Max. Mitre Cut (45 degrees x 0 degrees): 145mm x 55mm
- Max. Compound Cut (45 degrees x 45 degrees): 145mm x 38mm
- Mild Steel Plate (Max. Thickness): 6mm
- Mild Steel Box Section (Max. Wall Thickness): 3mm
- Product Dimensions: 290mm x 595mm x 565mm (with saw head down)
- Product Weight: 8.95 kg
- Cable Length: 3m
- Sound Pressure Level LPA: 110V: 91.9 dB(A) / 220-240V: 93.1 dB(A)
- Sound Power Level LWA: 110V: 104.9 dB(A) / 220-240V: 106.1 dB(A)
- Laser Class: Class 2
- Laser Source: Laser Diode
- Laser Output Power (Max): <1mW
- Wave Length (Nm): 650
Compatible With
- 185mm Multi-Material Cutting TCT Blade
- 185mm Diamond Blade
- Evolution Mitre Saw Stand
Items Included
- 20T Multi-Material TCT Blade
- 3pc Hold Down Clamp
- Machine Table Extensions
- Dust Collection Bag
- Dust Port Adaptor
- Double Ended Hex Key (M6 & M4)
- Front Clamp
- Ergonomic Rear Carry Handle
- 3m Cable
