General description
The 20,000lb (9,072kg) Original Orange Z Hydraulic Winch is designed for heavy-duty applications, making it ideal for recovery trucks, trailers over 7.5T, as well as industrial, commercial, and agricultural use. This winch features a robust construction and comes equipped with a twin wireless remote control for ease of operation.
Technical specifications
- Single line rated pull: 20,000lb (9,072kg)
- Motor: Hydraulic
- Gear train: 3 Stage Planetary
- Gear reduction ratio: 32:1
- Clutch: Sliding Ring Gear
- Braking Action: Automatic
- Drum size: Diameter 88mm, Length 222mm
- Cable: 25m x 14mm diameter galvanized steel wire rope
- Hook: 1/2 inch grade 70 forged clevis hook, zinc plated
- Fairlead: 4-Way Roller Fairlead
- Flow: 50-60 L/min
- Pressure: 10.8Mpa (108 Bar)
- Finish: Orange & Black
- Weight (GW): 70kg (154lb)
- Overall Dimensions: 548 x 196 x 249mm (LxWxH)
- Mounting Bolt Pattern: 10.00” x 4.50” (254 x 114.3mm)
- Pressure Hose Connections: 18mm/1.5mm
- No Load Line Speed: 6.5m/min (21.3 ft/min)
Usage
This hydraulic winch is suitable for a variety of applications, including:
- Recovery operations for vehicles and trailers
- Heavy lifting in industrial settings
- Assistance in agricultural tasks
Other information
Industry-leading lifetime warranty on mechanical components and 3 years warranty on electrical components. VAT invoice provided with every sale.
