5,000lb (2,268kg) Original Orange 12v Winch. 15m x 5mm Steel Rope, 1/4 Inch Clevis Hook, Twin Remote Controls.

Name: 5,000lb (2,268kg) Original Orange 12v Winch. 15m x 5mm Steel Rope, 1/4 Inch Clevis Hook, Twin Remote Controls.
Brand: WINCHMAX
SKU: WM500012V
Availability: OutOfStock

Product out of stock

Product information

Description

GENERAL DESCRIPTION

The 5,000lb (2,268kg) Original Orange 12v Electric Winch is designed for use on boat trailers, ATVs, and light utility vehicles. It includes a mounting plate and features twin wireless remote controls.

TECHNICAL SPECIFICATIONS

Rated Pull: 5,000lb (2,268kg)
Motor: 12v 1.5hp Permanent Magnetic Motor
Control: Twin Wireless Remote and Handlebar-Mounted Rocker Switch
Gear Train: 3 Stage Planetary
Gear Reduction Ratio: 166:1
Clutch: Cam Activated Free Spool
Braking Action: Automatic Full Load Hold
Drum Finish: Steel – Painted Black
Cable: 15.2m x 6.3mm Galvanized Steel Wire Rope
Hook: Clevis Hook 1/4 Inch, Zinc plated
Fairlead: 4 Way Roller Fairlead
Recommended Battery: 12Ah Minimum for Winching
Battery Leads: 10mm2 x 180cm
Motor Leads: 10mm2 x 90cm
Winch Finish: Original Orange powder-coated
Weight: 16.2kg (35.7lb)
Overall Dimensions: 390 x 120 x 117mm (LxWxH)
Motor Current: 15-296A
No Load Line Speed: 6.1m/min (20.0ft/min)

OTHER INFORMATION

Includes a strong WINCHMAX branded cover for protection against water and road grime. It is CE certified and built to ISO9001 quality management system requirements. The product comes with an industry-leading lifetime warranty on mechanical components and a 3-year warranty on electrical components.

Features

Brand
WINCHMAX
Origin
Made in China
Colour
Orange
Maximum load
2268 kg
Remote operation
Yes
Cable diameter
5 mm
Supplied with hauling pulley
Yes
IP rating
IP67
Width
12 cm
Length
39 cm
Material
Steel
Operating Mode
Electric
Weight
16.6 kg
Presence of brake
Yes
Power
1119 W
Power supply
Electric
Voltage
12 V
Winch operating type
Straight Line Pull
Remote control type
Radio remote control
Sold with cable
Yes
ManoMano Reference
ME56067250
MMID
103163758756
Product code
WM500012V
EAN
5060854570499

Advice from

Winch buying guide

A winch is a lifting and pulling tool. Are you the Hulk? Can you lift a heavy load yourself? A winch is essential. A rope, cord, or cable attached a drum winds up and raises or pulls a load on the other end. Depending on usage, they can be portable, stationary, manual, electric, or hydraulic.
