General description
The 13,500lb (6,123kg) Original Orange 12V Electric Winch is designed for heavy-duty applications, making it ideal for recovery trucks and 4x4 vehicles with a weight capacity of up to 3.5 tons. This powerful winch features a robust construction and advanced technology for reliable performance.
Technical specifications
- Single Line Rated Pull: 13,500lb (6,123kg)
- Motor: 12V 6.8hp/5.1kw, series wound
- Control: Remote switch with a 4.5m lead
- Gear train: 3 stage planetary
- Gear reduction ratio: 265:1
- Clutch: Sliding ring gear
- Braking Action: Automatic in the drum
- Drum size: Diameter 64mm (2.5”), length 224mm (8.82”)
- Drum finish: Black, painted
- Cable: 26m x 9.5mm galvanized steel wire rope
- Hook: Clevis hook 3/8 inch, zinc plated
- Fairlead: 4-Way Roller Fairlead
- Battery: Recommended 650CCA minimum for winching
- Battery Leads: 2 gauge, 1.83m (72”) 25mmsq - 5.6mm diameter
- Finish: Original Orange powder coated
- Weight (GW): 40kg (88lb)
- Overall Dimensions (LxWxH): 536 x 160 x 218mm (21.3” x 6.3” x 8.6”)
- Mounting Bolt Pattern: 10.00”±0.015” x 4.50”±0.010” (254 x 114.3mm)
- Motor Current: 65-500A
- No Load Line Speed: 6.5m/min (21.3 ft/min)
Usage
This winch is perfect for a variety of applications, including:
- Recovering vehicles stuck in mud or snow
- Pulling heavy loads in off-road situations
- Assisting in towing and lifting tasks
Other information
Industry-leading lifetime warranty on mechanical components and 3 years warranty on electrical components.
