General description
ANNKE 8CH CCTV Kit includes an NVR and 8×8MP cameras, designed for smart dual light remote monitoring and motion detection. This surveillance system is equipped with a 1TB HDD for storage, ensuring high-quality video recording and playback.Technical specifications
- Max Recording Resolution: Up to 12MP (4096 X 3072)@30fps
- Max Playback Resolution: Up to 12MP (4096 X 3072)@30fps
- Video Output: HDMI up to 4K (4096 × 2160), VGA up to 1080p (1920 × 1080)
- Operating Power: DC 48 V
- Power Consumption: ≤10 W (Without HDD and PoE)
- Working Temperature: 14 °F ~ 131 °F / -10 °C ~ +55 °C
- Dimensions (W X H X D): 12.4” X 9.4” X 1.9” / 315 X 240 X 48 mm
- Weight (Without Hard Disk): 2.2 lbs / 1 kg
- Camera Image Sensor: 1/2.4" Progressive Scan CMOS
- Camera Max Resolution: 3840*2160 (8MP)
- Camera Lens: 4 mm
- Camera Weight: 0.6 lb / 285 g
- Camera Dimensions (L X W X H): 170.8 mm × 66 mm × 69.1 mm (6.7" × 2.6" × 2.7")
Compatibility and accessories
- Supports up to 8 ANNKE IP cameras and other ONVIF cameras
- Compatible with 1MP to 8MP (4K) IP cameras
- Supports on-board storage up to 512 GB (SD card slot)
Installation
- Easy installation with built-in PoE inputs for connecting IP cameras
- Includes a user-friendly interface for setup and configuration
Usage
- Live view, recording, and playback of video up to 12 MP resolution
- Remote monitoring via iPhone, iPad, and Android devices
- Smart motion detection alerts with instant app pushes and email notifications
Other information
