General description
The ANNKE 8CH CCTV Kit includes an NVR and 8 high-definition 8MP cameras, designed for comprehensive remote monitoring and security. This system features smart dual light technology, motion detection capabilities, and built-in audio recording, making it ideal for both residential and commercial surveillance needs.Technical specifications
- Max Recording Resolution: Up to 12MP (4096 X 3072)@30fps
- Max Playback Resolution: Up to 12MP (4096 X 3072)@30fps
- Video Output: HDMI up to 4K (4096 × 2160), VGA up to 1080p (1920 × 1080)
- Operating Power: DC 48 V
- Power Consumption: ≤10 W (Without HDD and PoE)
- Working Temperature: 14 °F ~ 131 °F (-10 °C ~ +55 °C)
- Dimensions (W X H X D): 12.4” X 9.4” X 1.9” (315 X 240 X 48 mm)
- Weight (Without Hard Disk): 2.2 lbs (1 kg)
- Camera Dimensions (L X W X H): 170.8 mm × 66 mm × 69.1 mm (6.7" × 2.6" × 2.7")
- Camera Weight: 0.6 lb (285 g)
Compatibility and accessories
- Compatible with up to 8 ANNKE IP cameras and other ONVIF cameras
- Supports on-board storage up to 512 GB (SD card slot)
- 1 SATA Interface for HDD, supporting up to 8 TB Capacity
Installation
- Easy installation with built-in PoE inputs for camera connectivity
- Supports remote access via mobile devices (iPhone, iPad, Android)
Usage
- Live view and recording of up to 12 MP resolution
- Smart motion detection with customizable motion areas and privacy masks
- Receive instant alerts via app pushes and email notifications for motion events
