General description
The Inline Wall Fan CA 150 MD W EP is a robust centrifugal fan designed for efficient air extraction directly to the outside of a building. With a high flow rate of 617 m³/h and a durable construction, this fan is ideal for various ventilation needs. It features a selectable model option for quiet operation (CA 150 Q) and is suitable for both horizontal and vertical mounting.Technical specifications
- Voltage: 220-240 V ~ 50 Hz
- Nominal width: 150 mm
- Material: lacquered and galvanised steel sheet
- Colour: hammered grey
- Motor: encapsulated, ball-bearing with thermal overload protection
- IP rating: IP44 (splashing water), protection class II
- Service life: approximately 30,000 hours
- Max. ambient temperature for continuous operation: 50°C
- Weight: 5.5 kg (CA 150 MD W EP), 3.3 kg (CA 150 Q MD W EP)
Compatibility and accessories
- Model options: CA 150 MD W EP or CA 150 Q MD W EP (quiet operation)
- Protective grille available separately
Installation
- Easy installation with 4 screws (screws and dowels included)
- Mounting options: horizontal or vertical
- Easily accessible electric terminal strip
Usage
This inline wall fan is designed for effective air extraction, making it suitable for use in bathrooms, kitchens, and other areas requiring ventilation. The three-speed controller allows for adjustable airflow to meet specific needs.Other information
