General description
The PUNTO EVO ME 100 is a compact bathroom fan designed for efficient air circulation in small rooms. With a maximum airflow of 95 m³/h, it features a sleek white design and is constructed from durable, UV-resistant ABS synthetic material. This fan operates quietly, making it ideal for use in bathrooms and other small spaces.Technical specifications
- Voltage: 230 - 240 Volt / 50 Hertz
- Material: Shock-proof, UV-resistant ABS synthetic material
- Blade wheel: Diagonal, made of polypropylene
- Power consumption: 5 - 9 Watt
- Current: 0.039 - 0.052 Ampere
- Total pressure: 27.46 - 46.09 Pa
- Sound pressure (Lp-3m): 20.8 - 26.9 dB(A)
- Rotation speed: 1700 - 2240 rpm
- Airflow: 65 - 95 m³/h
- Protection code: IP45
- Weight: 0.56 kg
- Life span: Approximately 30,000 hours
Compatibility and accessories
- Available models: ME 100 LL, ME 100 LL T, ME 100 LL T PIR, ME 100 LL TP, ME 100 TP HCS
Installation
- Simple and quick installation
- Can be mounted in any position: horizontal, vertical, or diagonal
- Options for wall, ceiling, or porched mounting
Usage
- 2-speed operation for customizable airflow
- ME 100 LL T model features delayed switching off (3 - 20 min.)
- ME 100 LL T PIR model includes a motion sensor for automatic activation
- ME 100 LL TP model has a time delay timer for delayed switching on (45-120 sec.) and off (6, 10, 15, 21 min.)
- ME 100 TP HCS model includes a humidity sensor that activates the fan at a set humidity level (default 60%)
Other information
